In 2002, Jingzhongjing independently developed and built China's first automotive body repair and painting assembly line, pioneering the assembly line operation of body repair and painting in the domestic automotive repair industry. For over 20 years since then, it has continued to deepen its expertise, and its products have now obtained certifications from more than 35 automotive brands, covering almost all domestic and international automotive brands manufactured in China.
Jingzhongjing's sheet metal spraying production line adopts a lean production method, dividing the workshop into multiple functional areas, with specific operators completing specific processes, forming an assembly line operation mode.
1. Assembly line operation significantly improves efficiency.
The traditional bodywork and paint shop was transformed into a streamlined production line divided into work processes. Vehicles sequentially pass through each station: bodywork → putty → sanding → primer → masking → paint spraying and baking.
Each workstation has a dedicated person in charge, with specialized division of labor, which significantly shortens the repair cycle for a single vehicle.
With the car-mounted sliding trolley system, the vehicle can be manually pushed to change workstations without starting, maximizing space utilization.
2. Modular room design for flexible layout
Each workstation adopts a modular structure, combining EPS insulated wall panels and anti-static PVC soft curtains.
The number and layout of workstations can be flexibly adjusted according to the workshop area.
The electric roller shutter door (aluminum alloy sandwich/PU insulation) serves as a passageway between workstations, with a lifting speed of 0.2m/s, facilitating vehicle movement.
3. Intelligent ventilation system ensures a clean environment.
Each workstation is equipped with an independent air supply and exhaust system, using YDW series centrifugal fans (Siemens technology).
5.5KW centrifugal fan for grinding station, 4KW x 2 units for intermediate coating/spray painting station
Equipped with a micro-adjustable electric damper for precise control of air intake and exhaust volume.
The side exhaust design of the grinding station effectively collects dust.
4. The spray painting and baking station meets the standards of an independent paint booth.
Replacing EPS with 50mm rock wool wall panels provides a higher fire resistance rating.
32 36W fluorescent tubes provide ample illumination.
Electric roller shutters on both sides facilitate vehicle access, while the rear side features a sheet metal door.
It can perform spray painting and baking paint operations independently.
5. Well-developed environmental protection system
It can be linked with VOCs waste gas treatment equipment (activated carbon adsorption, catalytic combustion of CO, zeolite rotor + RTO/RCO, etc.)
Each workstation has independent exhaust ventilation, and waste gas is collected and treated separately.
Anti-static PVC soft curtains reduce dust accumulation
6. Compatible with water-based paints
The spray painting station can be equipped with a water-based paint drying system.
Infrared/3D heating lamps provide uniform heating, suitable for the low-temperature drying requirements of water-based paints.
Jingzhongjing's body and paint production line has provided the largest body and paint production line in China to several well-known auto repair groups:
The core value of Guangdong Jingzhongjing's body and paint assembly line lies in upgrading the automotive repair and body painting workshop from scattered single-station operations to an assembly line production model with process-based zoning, dedicated personnel, and orderly vehicle flow.
Its significant advantages can be summarized in five dimensions:
Founding Pioneer – In 2002, China's first automotive body panel and paint assembly line was built, with nearly 30 years of technological accumulation.
Extremely high brand recognition—certified by 35+ automotive brands, Audi's only designated body and paint assembly line manufacturer.
Modular and flexible configuration—Sheet metal work → putty → sanding → intermediate coat → masking → spray painting, combined as needed.
Independent air supply and exhaust at each workstation—Each workstation has its own independent air supply system to avoid cross-contamination and ensure a clean environment.
Full-chain service—providing a one-stop solution from pretreatment to waste gas treatment, with excellent equipment compatibility.
We have representatives in over 100 countries around the world, They provide dedicated after-sales support to ensure complete customer satisfaction and long-term operational confidence.
